| Swing | 14.9" | 378.46 mm |
| Centers | 60" | 1,524 mm |
| Power | 5 hp | 3.7 kW |
| Workhead Speed | 350 RPM | 350 RPM |
| Grinding Wheel Dia. | 16" | 406.4 mm |
| Max Weight Between Centers | 330 lb | 149.7 kg |
| Plunge (Yes/No) | No | No |
| Control | CNC (Pro-Face PLC Control) | CNC (Pro-Face PLC Control) |
| Dimensions | 196″ x 90″ x 66″ High Approx. | 196″ x 90″ x 66″ High Approx. |
| Weight | 12,100 lbs Approx. | 12,100 lbs Approx. |
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
Capacity:
Max Grinding Diameter: 14.17″
Max Grinding Length: 59.0″
Max load Capacity: 330 lbs
Swing Over Bed: 14.9″
Distance Between Centers: 60.0″
Wheelhead:
Grinding wheel Size: 16″ X 2″ X 5″
Speed: 1650 RPM
Wheelhead Motor Power: 5 HP
Maximum Infeed Travel: 9.64"
Workhead:
Spindle Speeds: 25 to 350 RPM
Spindle Center/Rotation: MT#4 / Dead & Live
Swiveling Angle: 90 degrees CCW
Table:
Table Speed: 2 to 118 IPM
Table Swivel Angle (CCW/CW): +5° /- 5°
Table Handwheel per Revolution: 0.39"
Table Minimum Traverse Length: 0.3″
Tailstock:
Tailstock Quill Stroke: 1.0″
Tailstock Taper: MT-4
General:
Power Source: AC 460 V Three Phase 60 Hz
Overall Dimensions: 196″ x 90″ x 66″ High Approx.
Weight : 12,100 lbs Approx.
Pro-Face PLC Control
Automatic Grinder Cycle (Rough Grind, Fine Grind, Spark out, Return)
Swing Down Internal Attachment
Tailstock Mounted Dresser
Coolant System
Hydraulic Unit
