Throat Depth: 10”
Ram Speeds: Fast Approach - 115 IPM, Slow Bend - 24 IPM, Fast Return - 200 IPM
Main Motor: 20 HP Wired: 440/60/3
| Tonnage | 100 T | 90.719 t |
| Type | HYD | HYD |
| Overall Length | 10' | 3 m |
| Between Housings | 8.33' | 2.5 m |
| Stroke | 8" | 203.2 mm |
| Control | CNC (ETS100) | CNC (ETS100) |
| Dimensions | 136” x 52” x 84”T | 136” x 52” x 84”T |
| Weight | 14,000 | 14,000 |
ETS100 Control, Adjustable Bend Speed, Machine Groove in Bed, Dual Ram Clamps, 3 x 3 x 10’ Die Holder with Tang, and User Manual
