| Swing | 27.2" | 690.88 mm |
| Machining Length | 100.4" | 2,550.2 mm |
| # Axis | 3 | 3 |
| Chuck Size | 24" | 609.6 mm |
| Bar Capacity | 9.3" | 236.22 mm |
| Power | 60 hp | 44.7 kW |
| Max RPM | 750 RPM | 750 RPM |
| Turning Dia | 36.6" | 929.64 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Control | CNC (Fanuc) | CNC (Fanuc) |
| Dimensions | 275" X 114" X 115 " High | 275" X 114" X 115 " High |
| Weight | 50000 lbs. Approx. | 50000 lbs. Approx. |
*All specifications are approximations and are subject to verification. Comes as shown in images. Please give us a call if you have any questions before purchasing. All sales are final.*
Features:
Fanuc 18iT CNC Control
A2-15 Spindle with 10" Bore
Schunk Rota TB-500 24" 3 Jaw Chuck with 10" Bore
60 HP Gearbox Spindle
PCMCIA Card Slot
Programmable Tailstock
Rigid Tapping
Coolant System
Foot Switch
Capacity:
Max Turning Diameter: 36.6"
Max Turning Length: 100.4"
Max Bar Capacity: 9.3"
Swing Over Bed: 27.2"
Swing Over Cross slide: 23.6"
Distance Between Centers: 98.46"
Travels:
X Axis Travel: 12.6"
Z Axis Travel: 98.4 "
w Axis Travel: 89.0" ?
Rapid Traverse X Axis: 630 IPM
Rapid Traverse Z Axis: 630 IPM
Spindle:
Spindle Nose: A2-15
Spindle Bore: 10.8"
Spindle Speed: 10 - 750 RPM
Spindle Motor: 60 HP
Turret:
Turret Capacity: 12 Stations
Turret Index Time: 0.4 Second
Turret Tool Type: BMT
Tailstock:
Tailstock Taper: MT-7
Quill Diameter: 7.9"
Quill Travel: 7.9"
Tailstock Body Travel: 86.7″
General:
Power: 78kva, 220v / 3-Phase
Overall Dimensions: 275" X 114" X 115 " High
Weight: 50000 lbs. Approx.
Boring Bar Slide ( W Axis )
SMW Hydraulic Steady Rest
Chip Conveyor
