8" X .075" Rapid-Air #108B, #29251
Coil Feed Types | Servo Feed | Servo Feed |
Max Width | 8" | 203.2 mm |
Max Thickness | 0.075" | 1.905 mm |
Dimensions | 17" L-R x 28" F-B x 28" H (feed); 16" L-R x 17" F-B x 42" H (control) | 17" L-R x 28" F-B x 28" H (feed); 16" L-R x 17" F-B x 42" H (control) |
Weight | 500 lbs. (total) | 500 lbs. (total) |
USED 8" X .075" RAPID-AIR SERVO FEED
Model no. 108B
Stock width: 8"
Stock thickness: .075"
Maximum feed roll opening: .150"
Roll diameter: 1.59"
Weight approx. 500 lbs. (total)
Overall dimensions approx. 17" L-R x 28" F-B x 28" H (feed)
16" L-R x 17" F-B x 42" H (control)
Serial no. 95915
Stock no. 29251
FOB ELK GROVE VILLAGE, IL
Free standing programmable control
Pendant control with pushbuttons for forward - reverse
Selector switch for rolls lower - raise
Stock edge guide
Press mounting bracket
