item unit HM503H
size mm 500×500
inch 19.7×19.7
max load kg 600
lb 1323
travel X/Y/Z mm 750×650×650
inch 25.4×25.6×25.6
rapid traverse X/Y/Z m/min 30/24/30
motor power Kw
spindlemax speed rpm 6000
magazine capacity pc 24（disc）
net weight kg 12000
lb 26460
| X | 750 mm | 29.528" |
| Y | 650 mm | 25.591" |
| Z | 650 mm | 25.591" |
| Pallet-W | 500 mm | 19.685" |
| Pallet-L | 500 mm | 19.685" |
