| Rect-Cap (H) | 22" | 558.8 mm |
| Rect-Cap (W) | 22" | 558.8 mm |
| Rounds-Cap | 22" | 558.8 mm |
| Power | 10 hp | 7.5 kW |
| Type (Auto, Manual, Semi) | Auto | Auto |
| Blade Width | 2" | 50.8 mm |
| Blade Length | 270" | 6,858 mm |
| Dimensions | 141″ x 88″ x 92″ | 141″ x 88″ x 92″ |
| Weight | 12,500 lbs | 12,500 lbs |
Specifications (subject to buyer verification):
Capacity at 90°: 22"
Rectangular: 22"
Round: 22″
Blade Dimensions: 22’6″ x 2
Blade Drive: 10 HP
Blade Speed: 40-300 SFM
Shuttle Stroke: 0-34″
Hydraulic Drive: 3 HP
Coolant Tank Capacity: 30 Gallons
Table Height-: Raised Up on Channel Beam
240 Volt 3Ph 33.4FLA
Weight: 12,500 lbs
Dimensions: 141″ x 88″ x 92″
Equipped With (subject to buyer verification):
Extremely heavy-duty guide arms and cast iron wheels
Heavy-duty full stroke vises
Hardened and replaceable wear strips
Carbide guides
Heavy duty gearbox and motor assembly
Variable frequency drive
Easy access servicing panels
Wash down hose
Powered blade brush
Hydraulic guide arm positioning
Hydraulic blade tension
Hydraulic chip auger
Blade breakage switch
