| Swing | 35.4" | 899.16 mm |
| Machining Length | 82.6" | 2,098 mm |
| Chuck Size | 24" | 609.6 mm |
| Bar Capacity | 6.5" | 165.1 mm |
| Power | 60 hp | 44.7 kW |
| Max RPM | 1,500 RPM | 1,500 RPM |
| Turning Dia | 35.4" | 899.16 mm |
| Tailstock | Yes | Yes |
| Dimensions | 249" x 87" x 86" | 249" x 87" x 86" |
| Weight | 25,500 lbs | 25,500 lbs |
Specifications (subject to buyer verification):
Chuck Size: 21"
Spindle Speed: 1,500 RPM
Spindle Motor: 60 HP
X Axis Travel: 14.3"
Z Axis Travel: 84.8"
Rapid Rate Z Axis: 710 IPM
Rapid Rate X Axis: 630 IPM
Turret Tools: 12 Station
Maximum Turning Diameter: 35.4"
Maximum Turning Length: 82.6"
Maximum Swing: 35.4"
Spindle Bore 6.5"
Spindle Nose A1-15
Dimensions: 249" x 87" x 86"
Weight: 25,500 lbs
Equipped With (subject to buyer verification):
Fanuc 32i CNC Control
Chip Conveyor
Tailstock
Fast 0.25 Second Turret Indexing
One-Piece 45 Degree Torque-Tube Slant Bed
Isolated 2-Speed Gearbox
Solid Box Way Construction
