TECHNICA ZSM 5100-815 CNC CENTER HOLE GRINDER
| Grinding Wheel Dia. | 60 mm | 2.3622" |
| Grinding Wheel Width | 1,100 mm | 43.307" |
| Control | CNC (Flat Panel Control) | CNC (Flat Panel Control) |
| Dimensions | 22" x 22" x 73" H | 22" x 22" x 73" H |
| Weight | 1,300# | 1,300# |
Specifications:
Maximum Workpiece Length: 43"
Minimum Workpiece Length: 2"
Workpiece Diameter: .315 - 4.92"
Maximum Workpiece Weight: 264#
Cone Angle of Ground Center Holes: 60 Degrees
Diameter of Center Holes Ground: .079 - 1.97"
Grinding Spindle Speeds (3): 4500/22500/13000
Hollow Quill Speed (Planetary Axis): 400 RPM
Travel of Grinding Cone: .030" - .197"
Approx. Dimensions: 22" x 22" x 73"H
Approx. Weight: 1300 #
Flat Panel Control
