| Maximum External Gear Diameter | 18" | 457.2 mm |
| Maximum Internal Gear Diameter | 18" | 457.2 mm |
| Diametral Pitch | 4 | 4 |
| Stroke | 5" | 127 mm |
| Control Manufacturer | Conventional | Conventional |
Specifications:
Maximum Pitch Diameter (External): 18"
Maximum Pitch Diameter (Internal): 18"
Maximum Face Width, External & Internal: 5"
Maximum Diametrical Pitch Spur: 4 DP
Maximum Diametral Pitch Helical: 6 DP
Bore Through Work Spindle: 5 7/8"
Maximum Clearance Height: 16"
Cutter Spindle Diameter: 2.875"
Maximum Helix Angle With Proper Guide: 30 degrees
Stroking Speeds: 50-300 SPM
Dimensions (L x H x W): 63" x 90" x 48"
Machine Net Weight, Approximate: 7,500#
5" Stroke
5.875" work spindle bore
Hollow cutter spindle
Change gear set up
