| Type | All Electric | All Electric |
| Clamping Force Tonnage | 82.7 T | 75.024 t |
| Barrel Code | 2B | 2B |
| Shot Volume (PS) | 4.2 oz | 119.1 g |
| Screw Diameter | 1.42" | 36.068 mm |
| Maximum Injection Pressure | 25200 psi | |
| Maximum Holding Pressure | 25200 psi | |
| Screw Speed STD | 12.4 rpm | 12.4 RPM |
| Plasticizing Capacity (PS) STD | 0.8 oz | 22.7 g |
| Nozzle Touch Force | 1.1 T | 0.998 t |
| Tie Bar Distance H | 16.1" | 408.94 mm |
| Tie Bar Distance V | 14.2" | 360.68 mm |
| Platen Dimension H | 22.8" | 579.12 mm |
| Platen Dimension V | 20.9" | 530.86 mm |
| Clamp Stroke | 11.8" | 299.72 mm |
| Maximum Daylight | 30.3" | 769.62 mm |
| Mold Height Min | 5.9" | 149.86 mm |
| Mold Height Max | 18.5" | 469.9 mm |
| Ejector Force | 2.2 T | 1.996 t |
| Ejector Stroke | 2.8" | 71.12 mm |
| Injection Orientation | Horz | Horz |
| Hours | 57,000 hr. | 57,000 hr. |
| Control | CNC (InjectvisorV50) | CNC (InjectvisorV50) |
| Dimensions | 13.5 x 3.9 x 5.2 ft | 13.5 x 3.9 x 5.2 ft |
| Weight | 7200 | 7200 |
