Table Size – 10” x 50”
T-Slots – 3” x 5/8”
Table Travel – 32”
Saddle Travel – 16”
Knee Travel – 16”
Maximum Quill Travel – 5”
Quill Diameter – 86 mm
Spindle Taper – R8
Spindle Speed Range – 60-4200 RPM
Head Tilt – +/- 90
Spindle Motor Power – 3 HP
Power Requirement Control – 110V; 1P; 8A
Power requirements, machine - 220/440V;3P; 8.5/4.25A
Maximum Weight on Table – 850 lbs.
Machine Weight – 2800 lbs.
Machine dims l,w,h, - 78” x 103” x 69”
Maximum rapid feed – 100 IPM
Precision 7207 CP4 spindle bearings
Chrome hardened and ground quill
Meehanite castings
Slide ways are Turcite coated
Wide way surfaces are hardened and ground
