1450 Ton, 344 Oz. Wide Platen Toshiba Injection Molding Machine '02
Model: ISG1450DWV21-150B
Year | 2002 | 2002 |
Tonnage | 1450 | 1450 |
Shot Size | 344 | 344 |
Platen Size | 78.3" x 78.1" | 78.3" x 78.1" |
Tie Bar Spacing | 55.1" x 55.1" | 55.1" x 55.1" |
Mold Height (Min) | 27.6" | 27.6" |
Mold Height (Max) | 47.3" | 47.3" |
Daylight | 98.4" | 98.4" |
Ejector Stroke | 9.8" | 9.8" |
Ejector Force | 31 Tons | 31 Tons |
Clamp Stroke | 51.2" x 70.9" | 51.2" x 70.9" |
Screw Diameter | 5.51"/140mm | 5.51"/140mm |
LD Ratio | 10:1 | 10:1 |
Voltage | 450 Volts | 450 Volts |
Core Pull | Yes | Yes |
Control | V-21 | V-21 |
Horz/Vert | Horz | Horz |
Control | CNC | CNC |
Dimensions | 37.9' (L) x 10.5' (W) x 10.4'(H) | 37.9' (L) x 10.5' (W) x 10.4'(H) |
Weight | 141,000 lbs. | 141,000 lbs. |
Screw Displacement: 21.5 Lbs.
Intensification Ratio: 10.0:1
Max PPSI: 19,900ppsi
Max Injection Velocity: 3.33"/Sec
Clamp Dimensions: Clamp Dim: 20' (L) x 10' (W) x 8' (H)
Clamp Weight: 98,000 Lbs.
344 Oz. Injection Unit
Dual Core Pull
Valve Gates
SPI Interface
