2017 Mazak Integrex i-200 ST Multi-Axis CNC Lathe, Sub-Spindle, 12000 RPM Milling Spindle, Y-Axis, B-Axis, C-Axis, Chip Conveyor
| Max Swing | 25.91" | 658.11 mm |
| Max Swing (Lower Turret) | 16.14" | 409.96 mm |
| Max Dia (Upper turret) | 25.91" | 658.11 mm |
| Max Dia (Lower turret) | 16.14" | 409.96 mm |
| Machining Length | 59.8" | 1,518.9 mm |
| # Axis | 8 | 8 |
| Chuck Size (Main) | 8" | 203.2 mm |
| Chuck Size (Sub) | 8" | 203.2 mm |
| Bar Capacity (Main) | 2.56" | 65.024 mm |
| Bar Capacity (Sub) | 2.56" | 65.024 mm |
| Spindle Bore (Main) | 2.99" | 75.946 mm |
| Spindle Bore (Sub) | 2.99" | 75.946 mm |
| Power (Main) | 30 hp | 22.4 kW |
| Power (Sub) | 25 hp | 18.6 kW |
| Power (Milling Tool) | 30 hp | 22.4 kW |
| Max RPM (Main) | 5,000 RPM | 5,000 RPM |
| Max RPM (Sub) | 5,000 RPM | 5,000 RPM |
| RPM (Milling Spindle) | 12,000 RPM | 12,000 RPM |
| X-Axis Travel | 24.21" | 614.93 mm |
| Y-Axis Travel | 9.84" | 249.94 mm |
| B-Axis Rotation | -30° ~ 210° | -30° ~ 210° |
| Z-Axis Travel | 62.4" | 1,585 mm |
| W-Axis Travel | 40.39" | 1,025.9 mm |
| Spindle Nose (Main) | A2-6 | A2-6 |
| Spindle Nose (Sub) | A2-6 | A2-6 |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | Yes | Yes |
| Rapid Traverse (X/Z) | 1,968 in/min. | 1,968 in/min. |
| Rapid Traverse (Y) | 1,574 in/min. | 40 m/min. |
| Turret Capacity (Lower) | 9 | 9 |
| ATC Positions | 72 | 72 |
| Made In | Japan | Japan |
| Control | CNC (Mazatrol PC-Fusion) | CNC (Mazatrol PC-Fusion) |
| Weight | 49,720 lb | 49,720 lb |
Sub-spindle
12,000 rpm milling spindle
36 atc
Y-axis
B-axis
C-axis
Chip conveyor
