| Swing | 24" | 609.6 mm |
| Machining Length | 49.21" | 1,249.9 mm |
| # Axis | 2 | 2 |
| Chuck Size | 15" | 381 mm |
| Bar Capacity | 4.33" | 109.98 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 3,000 RPM | 3,000 RPM |
| Turning Dia | 16.53" | 419.86 mm |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Control | CNC (Okuma OSP E100L) | CNC (Okuma OSP E100L) |
| Dimensions | 128 x 75 x 79 | 128 x 75 x 79 |
| Weight | 16500 | 16500 |
Specifications (subject to buyer verification):
Maximum Swing Over Bed: 24”
Main Spindle Chuck Size: 15” 3-Jaw
Maximum Turning Diameter:16.53
Maximum Turning Length: 49.21”
X-Axis (Cross Travel): 11.81”
Z-Axis (Longitudinal Travel): 50.19”
Spindle Bore: 4.33”
Spindle Nose: A2-11
Spindle Horsepower: 30 HP
Spindle Speed Range: 28 – 3,000 RPM
Feed Range (Infinitely Variable): 0.1 – 400 IPM
X-Axis Rapid Traverse Rate: 787 IPM
Z-Axis Rapid Traverse Rate: 984 IPM
Machine Dimensions: 128” x 75” x 79”
Machine Weight: 16,500 lbs
Equipped With (subject to buyer verification):
Okuma OSP E100L CNC Control
Chip Conveyor
* No Steady Rest with Machine
