2000 Trumpf TrumaBend V130 Hydraulic CNC Press Brake, 130 Ton, 6-Axis Backgauge, CNC Crowning, Upper/Lower Manual Tool Clamping, Pneumatic I-Axis, Light Curtains, Front Supports
| Tonnage | 130 T | 117.934 t |
| Type | HYD | HYD |
| OA Length | 10' | 3 m |
| OA (Overall) Length | 120" | 3,048 mm |
| Between Frames | 106" | 2,692.4 mm |
| Throat Depth | 16" | 406.4 mm |
| Stroke | 8.5" | 215.9 mm |
| # Axis | 8 | 8 |
| Motor Power | 25 hp | 18.6 kW |
| Open Height | 15" | 381 mm |
| Bed Width | 4.75" | 120.65 mm |
| Fast Approach | 472 in/min. | 12 m/min. |
| Slow Bend | 24 in/min. | 0.6 m/min. |
| Fast Return | 320 in/min. | 8.1 m/min. |
| Control | CNC (Delem DA69) | CNC (Delem DA69) |
| Dimensions | 144" X 87" X 114" | 144" X 87" X 114" |
| Weight | 24,806 lb | 24,806 lb |
6-axis CNC backgauge
CNC crowning
Manual tool clamping (upper & lower)
Pneumatic I-axis (die shift)
Light curtains
Pedestal control
Front supports
