2021 UNIFIED FLEX DOY100 STAND-UP POUCH BAGGER WITH 2 HEAD LINEAR SCALE
Brand: Unified Flex
Model: DOY 100
Serial No. UN20210805
Mfg Date: 2021
Electrical power supply: AC single phase 220V, 60 Hz, 4 Amp
Power consumption: 0.79 KW
General
Bag width: 4" - 13”
Bag Length: 6"" - 14""
Maximum speed: Up to 17 bags/minute
Horizontal jaw activation: Pneumatic
Suction Source: Vacuum Generator
Electronic control: Omron PLC
Human Machine Interface (HMI): 7"" Touch Panel
Compressed air volume: 20 CFM
Air pressure: 80 psi
Temperature Control: Omron PID
Accessories (Includes)
DOY - Zipper Opening Accessory (Included)
Quick Disconnect Assembly for DOY100 Transition Shoot (Included)
2 Head Linear Scale (included)
Electrical Power Supply: AC single phase 220V / 60 Hz
Power Consumption: 1.2 KW
Up to 30 Cycles/min
Min. weight: 50 gm
Max weight: 2 kg
Weighing Accuracy: Within 2%
4.5L bucket volume
25L product receiving hopper
Memory for 20 recipe
Pneumatic bucket opening
Bulk vibratory control linear pan
Automatic cyclical or specified zeroing
Digital load cells weighing module
Floor Stand For 2 Head Linear Scale (Included)
Welded structure for mounting scale
Clearance: 6 foot clear
Scale dimensions: 33'' x 43'' x 41''
Floor stand dimensions: 48'' x 48''
MACHINE DIMENSIONS: 48'' x 24'' x 65''
| Dimensions | 48'' x 24'' x 65'' | 48'' x 24'' x 65'' |
2021 UNIFIED FLEX DOY 100 STAND-UP POUCH BAGGER WITH 2 HEAD LINEAR SCALE
Brand: Unified Flex
Model: DOY 100
Serial No. UN20210805
Mfg Date: 2021
Electrical power supply: AC single phase 220V, 60 Hz, 4 Amp
Power consumption: 0.79 KW
General
Bag width: 4" - 13”
Bag Length: 6" - 14"
Maximum speed: Up to 17 bags/minute
Horizontal jaw activation: Pneumatic
Suction Source: Vacuum Generator
Electronic control: Omron PLC
Human Machine Interface (HMI): 7" Touch Panel
Compressed air volume: 20 CFM
Air pressure: 80 psi
Temperature Control: Omron PID
Accessories (Includes)
DOY - Zipper Opening Accessory (Included)
Quick Disconnect Assembly for DOY100 Transition Shoot (Included)
2 Head Linear Scale (included)
Electrical Power Supply: AC single phase 220V / 60 Hz
Power Consumption: 1.2 KW
Up to 30 Cycles/min
Min. weight: 50 gm
Max weight: 2 kg
Weighing Accuracy: Within 2%
4.5L bucket volume
25L product receiving hopper
Memory for 20 recipe
Pneumatic bucket opening
Bulk vibratory control linear pan
Automatic cyclical or specified zeroing
Digital load cells weighing module
Floor Stand For 2 Head Linear Scale (Included)
Welded structure for mounting scale
Clearance: 6 foot clear
Scale dimensions: 33" x 43" x 41"
Floor stand dimensions: 48" x 48"
MACHINE DIMENSIONS: 48" x 24" x 65"
