SERIAL ................. 28560
MODEL .................. 6A GEAR SHAPER
PITCH DIAMETER ......... (External) 18"
PITCH DIAMETER ......... (Internal) 18"
FACE WIDTH ............. 5"
PITCH SPUR ............. 4 DP
PITCH HELICAL .......... 6 DP
BORE SPINDLE ........... 5-7/8"
CLEARANCE HEIGHT ....... 16"
SPINDLE DIAMETER ....... 2.875"
MAX HELIX ANGLE ........ 30 DEGREE
STROKE SPEEDS .......... 50 TO 300 SPM
STROKE ................. 5"
RISER .................. 10"
TABLE BORE .............
5-7/8"
