SERIAL ........................ 9J41V5R-6
MODEL ......................... 430
AREA OF TABLE ................. 80" X 18"
SPINDLE SPEEDS ................ (24) 16 TO 1600 RPM
LONGITUDINAL & CROSS FEEDS .... (32) 3/8 TO 90 IPM
VERTICAL FEEDS ................ (32) 3/16 TO 45 IPM
LONGITUDINAL TABLE TRAVEL ..... 42"
CROSS TABLE TRAVEL ............ 16"
VERTICAL HEAD TRAVEL .......... 24"
TAPER IN SPINDLE .............. #50 NS
DEPTH OF THROAT ............... 22-1/2
LONGITUDINAL & CROSS RAPIDE ... 150 IPM
VERTICAL RAPID TRAVERSE ....... 75 IPM
POWER DRAW BAR ................ YES
COOLANT ....................... YES
SPINDLE MOTOR ................. 30 HP
FEED MOTOR, HORSEPOWER ........ 7-1/2
Specifications
