SERIAL ................................. 191087
MODEL .................................. KRTC-11A
DIAMETER OF MAGNETIC CHUCK ............. 42-1/2"
MAXIMUM HEIGHT UNDER WHEEL ............. 24"
MAXIMUM SWING INSIDE GUARDS ............ 45"
SEGMENT WHEEL SIZE ..................... 22" DIAMETER
TABLE SPEEDS (4) ....................... 10,15,20,30 RPM
AUTOMATIC DOWNFEED RATES ............... .004" TO .012" IPR
WHEEL SPEED ............................ 700 RPM
COOLANT IN BASE ........................ YES
MAGNETIC SEPARATOR ..................... YES
AUTOMATIC LUBE SYSTEM .................. YES
SPINDLE MOTOR .......................... 50 HORSEPOWER
