SERIAL ............. 8500325
CONTROLS ........... AMADA NC9-EX
MODEL .............. FBD8025E
SERIAL ............. 8500325
CONTROLS ........... AMADA NC9-EX
MODEL .............. FBD8025E
SERIAL ............. 8500325
CONTROLS ........... AMADA NC9-EX
Tonnage: 88 Tons
Overall length bed/ram: 98.4”
Ram depth stop style: CNC controlled
Distance between housings: 86.6”
Upacting or downacting: Upacting
Backgauge range: 20”
Number of gauging axis’: 3
Backgauge speed: 1,100 IPM
R axis travel: 3”
Manual or powered Z axis: Manual
Stroke length: 3.94”
Throat depth: 15.75”
Ram clamps (sectionalized or solid bar): Sectionalized
Hydraulic or manual clamping: Manual
Die space (open height): 14.57”
Die space (closed height): 10.63”
Number of cylinders: 2
Advance speed: 180 IPM
Pressing speed: 17 IPM
Return speed: 175 IPM
Main motor: 7 H.P.
Voltage: 220 / 440 volt 3 phase
Oil tank capacity: 14.5 gallons
Air requirmnts: 60 PSI
Specifications
