11.81" X 17.7" CNC Turning Center with Okuma OSP P300L CNC Control, LNS Move 2 Barfeeder, Live Tooling, Tool Setting Probe, Programmable Tailstock, 10" 3 - Jaw Power Chuck, 12 Position ID/OD Tool Turret, Chip Conveyor and Coolant System
GENERAL SPECIFICATIONS Max Swing Over Slant Bed: 20.47"Max Swing Over Cross Slide: 14.57"Max Distance Between Centers: 20"Maximum Cutting Diameter: 11.81"Maximum Turning Length: 17.7"Chuck Size: 10"Cross Travel (X-Axis): 9.25"Longitudinal Travel (Z-Axis): 20.47"Rapid Traverse Rate: 787 IPMNumber of Turrets: 1Turret Positions: 12Spindle Nose: A2-8Spindle Bore: 3 15"Spindle Speed: 25 - 3000 RPMSpindle Drive Motor: 15 HPMilling Spindle Speed: 100-4500 RPMMilling Spindle Motor: 9 HPElectrical: 230/3/60Approximate Machine Dimension: 70" X 100"Approximate Machine Height: 68"Approximate Machine Weight: 9000 LBSINCLUDES: Okuma OSP P300L CNC Control, LNS Move 2 Barfeeder Live Tooling, Tool Setting Probe, Programmable Tailstock, 10" 3 - Jaw Power Chuck, 12 Position ID/OD Tool Turret, Chip Conveyor and Coolant System
